Product Features

Key Features of OPC Server 320 include:

Suitable for projects that have already purchased the legacy SunWare OPC DA Server software, with no need to repurchase the full suite.

  •
    Multi-Standard Compatibility Compliant with the latest OPC Data Access (DA) 1.0, 2.04, 2.05, and 3.0 standards.
  • Alarms and Events Support Compliant with the latest OPC Alarms and Events (A&E) 1.0 and 1.2 standards.
  • XML Data Access Compliant with the latest OPC XML Data Access 1.0 standard.
  • Highly Integrated System Perfectly integrates the OPC Data Access Server and Alarms & Events Server into a single application.
  • Rapid Tag Creation Built-in Tag Multiplier allows you to rapidly create hundreds of tags in seconds.
  • Hierarchical Management Supports categorizing tags into different logical folders, greatly enhancing management convenience.
  • Built-in Simulation Tools Supports numerical simulation testing for any data item within the OPC Server.
  • Range Configuration Tags support customizable upper and lower limit range information.
  • Flexible Configuration Provides highly flexible setup and configuration methods for large amounts of tags.
  • Custom Alarms Each tag can have independently customized alarm trigger conditions.
  • Value Persistence Tag values feature persistent storage capabilities.
Classic Core

Original OPC DA Server

Positioning: A high-performance communication core designed for internal closed plant networks and localized SCADA / HMI systems.

Product Overview

This product is specially built for field data acquisition in industrial automation, featuring a mature and stable device driver core. Having passed OPC Foundation (CTT) compliance testing, it quickly connects to various brands of PLCs, Inverters, smart meters, and field I/O modules. It standardizes complex hardware register data, providing seamless access for localized SCADA, HMI, and monitoring software.

Core Features

  •
    Broad Industrial Driver Support Built-in mainstream industrial protocols (Modbus RTU/TCP, dedicated communication drivers for major PLC brands), providing high sampling frequencies and low-latency data exchange.
  • Standard OPC DA 2.05a / 3.0 Compatibility Native support for Windows COM/DCOM communication standards, compatible with various commercially available SCADA brands (such as iFIX, InTouch, WinCC, Citect, etc.).
  • Hierarchical Tag Management Supports Group and Item tree management, providing intuitive data point searching, real-time value monitoring, and offline simulation debugging tools.
  • High Stability for Continuous Operation Equipped with automatic reconnection upon communication interruption, timeout protection mechanisms, and packet diagnostic logging to ensure 24/7 uninterrupted production line monitoring.
Recommended Upgrade
Dual Protocol / Upgrade Module

Superimposed OPC UA Server

Positioning: Built on the original OPC DA driver core, it seamlessly superimposes the OPC UA Wrapper / Server architecture, designed specifically for IT/OT convergence, remote cross-network connections, and IIoT smart manufacturing upgrades.

Product Overview & Architectural Advantages

"No need to reconfigure tags, zero changes to the original architecture, instantly equipping you with modern industrial cybersecurity capabilities."

This product utilizes a shared core architecture. The bottom layer directly inherits the stable OPC DA field driver acquisition module, while the top layer superimposes a highly efficient OPC UA server. Users do not need to reconfigure equipment tags or communication parameters; data tags originally defined in DA are automatically mapped to the OPC UA Namespace. It simultaneously supports concurrent connections from traditional OPC DA Clients and modern OPC UA Clients, serving as the optimal path for upgrading existing enterprise systems toward smart manufacturing and enhanced cybersecurity.

Why Upgrade to UA? (Core Value of Superimposed Architecture)

  • Farewell to DCOM Nightmares, Single-Port Firewall Traversal Completely eliminate the complex permission settings and firewall blocking issues associated with Microsoft Windows DCOM. By adopting a single standard communication port (opc.tcp://), it easily achieves cross-subnet, cross-router, and remote network connections.
  • Industry 4.0 Cybersecurity Defense Mechanisms Built-in comprehensive OPC UA security standards, supporting X.509 digital certificate authentication, AES-256 / SHA-256 communication encryption, and user account/password access control to prevent communication eavesdropping and tampering.
  • Parallel New and Legacy Systems (Dual-Channel Sharing) On-premise SCADA can continue to read devices via OPC DA, while upper-level IT systems, MES, ERP, EMS (Energy Management Systems), or cloud IoT Gateways can simultaneously collect data directly via encrypted OPC UA without mutual interference.
  • Structured Information Modeling Transforms the originally flat DA tags into a standard OPC UA object node architecture, supporting richer data types and status metadata.

Technical Specifications Comparison

Evaluation Dimension Original OPC DA Server (Basic Version) Superimposed OPC UA Server (Dual-Protocol Version)
Underlying Driver Source Dedicated Industrial Device Driver Core Inherits Existing DA Driver Core (Shared Memory Tags)
Supported Protocols OPC DA (2.05a, 3.0) OPC DA + OPC UA (Dual Server)
Communication Protocol Architecture Microsoft COM / DCOM TCP/IP Stack (opc.tcp://) + COM/DCOM
Network Traversal Capability Limited to Local PC or Same Subnet LAN Supports Cross-Subnet, Cross-Router, and Remote Connections
Cybersecurity Protection Relies on Windows User and OS Permissions X.509 Certificate Exchange, TLS/AES Encryption, Account Authentication
Upper-Level System Integration Traditional On-Premise SCADA / HMI Modern SCADA, MES, EMS, Cloud Platforms, Web SCADA
Tag Configuration Cost Requires Manual Creation/Import of Field Tags 0-Minute Reconfiguration (Directly Reads Existing DA Tag Projects)
Applicability In-Plant Single Machine / Isolated Closed Monitoring Sites Smart Factories, Cross-Plant Data Integration, Sites with Networked Security Requirements
Manufacturer Product ID Models type Specifications Price Protocol/Download
Advantech OPC30CE-MDS-O ADAM 4000 series Serial Modbus X86 XScale
Advantech OPC30CE-MDE-O ADAM 6000 series Ethernet Modbus TCP X86 XScale
Allen Bradley OPC30CE-ABS-O PM3000 power meter Serial DF1 Master X86 XScale
Allen Bradley OPC30CE-ABS-O PLC 5/10, PLC 5/15, PLC 5/20, PLC5/20C, PLC5/25, PLC5/30, PLC5/40, PLC5/40C, PLC 5/60, PLC 5/80, PLC5/80C Serial DF1 X86 XScale
Allen Bradley OPC30CE-ABS-O SLC 500 Fixed I/O, SLC 5/01, SLC 5/02, SLC 5/03, SLC 5/04, SLC 5/05 Serial DF1 X86 XScale
Allen Bradley OPC30CE-ABS-O MicroLogix 1000, MicroLogix 1100, MicroLogix 1200, MicroLogix 1500 Serial DF1 X86 XScale
Allen Bradley OPC30CE-ABE-O AB PLC5 Ethernet Ethernet ABNet X86 XScale
Allen Bradley OPC30CE-ABE-O AB SLC5/05 Ethernet Ethernet ABNet X86 XScale
Allen Bradley OPC30CE-ABCS-O ControlLogix, CompatLogix, FlexLogix, DriveLogix Serial DF1 X86 XScale
Allen Bradley OPC30CE-ABCE-O ControlLogix, GuardLogix, CompatLogix, FlexLogix, DriveLogix, SoftLogix Ethernet Ethernet/IP X86 XScale
Allen Bradley OPC30CE-ABDH-O MicroLogix: MicroLogix 1000, MicroLogix 1200, MicroLogix 1200R, MicroLogix 1500 Serial DH485 X86 XScale
Allen Bradley OPC30CE-ABDH-O PLC5: PLC5/10, PLC5/15, PLC5/20, PLC5/20E, PLC5/25, PLC5/30, PLC5/40, PLC5/40E, PLC5/60, PLC5/80, PLC5/80E Serial DH485 X86 XScale
Allen Bradley OPC30CE-ABDH-O SLC500: SLC 5/01, SLC 5/02, SLC 5/03, SLC 5/04, SLC 5/05 Serial DH485 X86 XScale
April OPC30CE-MDS-O A2000, A5000, A7000, PB200, PB400, PB80 Serial Modbus X86 XScale
Chessel OPC30CE-MDS-O 418G1 and 425000G Video Graphic Recorder Serial Modbus X86 XScale
Chessel OPC30CE-MDE-O 4100G Video Graphic Recorder Ethernet Modbus TCP X86 XScale
Chessel OPC30CE-MDE-O 5000 Series Graphic DAQ Recorder Ethernet Modbus TCP X86 XScale
Control Microsystems OPC30CE-MDS-O SCADAPack PLC / RTU Series. Models: SCADAPack 100, 32, LP, SmartWIRE Serial Modbus X86 XScale
Delta OPC30CE-DLS-O DVP-ES, DVP-EX, DVP-SS, DVP-SA, DVP-SX, DVP-SC, DVP-EH, DVP-EH2, DVP-SV, DVP-PM Serial Delta X86 XScale
Delta OPC30CE-DLE-O DVP-SV Ethernet Delta X86 XScale
Eurotherm OPC30CE-MDS-O T103 redundant processor unit controller Serial Modbus X86 XScale
Eurotherm OPC30CE-MDS-O Process Automation T640 and T630 Controllers Serial Modbus X86 XScale
Eurotherm OPC30CE-MDS-O 800 Visual Supervisor Serial Modbus X86 XScale
Eurotherm OPC30CE-MDS-O 2500 Controller / Control System Serial Modbus X86 XScale
Eurotherm OPC30CE-MDS-O BUSWARE E-Series Ethernet I/O modules Serial Modbus X86 XScale
Fatek OPC30CE-FKS-O FBs-20MN, FBs-32MN, FBs-44MN, FBs-10MC, FBs-14MC, FBs-20MC, FBs-24MC, FBs-32MC, FBs-40MC, FBs-60MC, FBs-10MA, FBs-14MA, FBs-20MA, FBs-24MA, FBs-32MA, FBs-40MA, FBs-60MA Serial Fatek X86 XScale
Fatek OPC30CE-FKE-O FBs-20MN, FBs-32MN, FBs-44MN, FBs-10MC, FBs-14MC, FBs-20MC, FBs-24MC, FBs-32MC, FBs-40MC, FBs-60MC, FBs-10MA, FBs-14MA, FBs-20MA, FBs-24MA, FBs-32MA, FBs-40MA, FBs-60MA Ethernet FatekNet X86 XScale
Festo OPC30CE-FSS-O FC30, FC34, FC400, FC440, FC600, FC640, FC660 Serial Serial Fst X86 XScale
Festo OPC30CE-FSE-O FC34, FC400, FC440, ,FC600, FC640, FC660 Ethernet CI Ethernet X86 XScale
Fisher Controls OPC30CE-MDS-O Fisher ROC Flow meter RTU via modbus. Models 306, 312, 364 Serial Modbus X86 XScale
Fisher - Rosemount OPC30CE-MDS-O EC300 Controller Serial Modbus X86 XScale
Fisher - Rosemount OPC30CE-MDS-O FloBoss Flow meter RTU via modbus. Models 103, 407, 503 to 553, 2500 Turbo, S600 Serial Modbus X86 XScale
Fuji OPC30CE-FJT-O Micrex F PLC (Tlink) Serial T Links X86 XScale
Fuji OPC30CE-FJS-O SPH200, SPH300, SPH300EX, SPH2000, SPH3000, SPH3000MM Serial Loader Command X86 XScale
Fuji OPC30CE-FJE-O SPH200, SPH300, SPH300EX, SPH2000, SPH3000, SPH3000MM Ethernet Loader Command X86 XScale
Gantner OPC30CE-MDS-O ISM series Serial Modbus X86 XScale
GE Fanuc OPC30CE-GES-O 9030-311, 9030-313, 9030-323, 9030-331, 9030-340, 9030-341, 9030-350, 9030-351, 9030-352, 9030-360, 9030-363, 9030-364, 9030-374, 9070-731, 9070-732, 9070-772, 9070-780, 9070-782, 9070-788, 9070-789, 9070-790, 9070-915, 9070-925, Micro, VersaMax CPU-001, VersaMax CPU-002, VersaMax CPU-005, VersaMax CPU-E05, RX3i PAC(Not support SNP-X) Serial SNP X86 XScale
GE Fanuc OPC30CE-GES-O 9030-311, 9030-313, 9030-323, 9030-331, 9030-340, 9030-341, 9030-350, 9030-351, 9030-352, 9030-360, 9030-363, 9030-364, 9030-374, 9070-731, 9070-732, 9070-772, 9070-780, 9070-782, 9070-788, 9070-789, 9070-790, 9070-915, 9070-925, Micro, VersaMax CPU-001, VersaMax CPU-002, VersaMax CPU-005, VersaMax CPU-E05, RX3i PAC(Not support SNP-X) Serial SNP-X X86 XScale
GE Fanuc OPC30CE-GEE-O 9030-311, 9030-313, 9030-323, 9030-331, 9030-352, 9030-350, 9030-360, 9030-363, 9030-364, 9030-374, 9070-772, 9070-782, 9070-788, 9070-789, 9070-790, 9070-928, 9070-935, VersaMax CPU-E05,RX3i PAC Ethernet SRTP X86 XScale
GrayHill OPC30CE-MDS-O OpenLine IO Modules Serial Modbus X86 XScale
GSM Modem OPC30CE-GSM-O Support the hardware which provide the Wavecom compatible chips. Serial GSM Modem X86 XScale
Hitachi OPC30CE-HIS-O MICRO-EH, EH-150, H-200, H-20, H-300, H-700, H-2000, H-2002, H-702, H-302, H-1002, H-4010 Series Serial H-Protocol X86 XScale
Hitachi OPC30CE-HIE-O EH-150, H-300, H-700, H-2000, H-2002, H-702, H-302, H-1002, H-4010 Series Ethernet H-Protocol X86 XScale
Hitachi OPC30CE-HII-O Support Hitachi SJ-300 all series Inverter Serial SJ300 Protocol
I7300 OPC30CE-MDS-O I-7300 Power Meter Serial Modbus X86 XScale
ICP OPC30CE-MDS-O M-7000 Serial Modbus X86 XScale
IDEC OPC30CE-IDS-O MicroSmart, Micro3, OpenNet Controller Serial IDEC X86 XScale
Kato OPC30CE-MDS-O Kato Power Meter Serial Modbus X86 XScale
Keyence OPC30CE-KES-O KV-700, KV-1000, KV-3000, KV-5000 Serial Keyence X86 XScale
Keyence OPC30CE-KEE-O KV-700, KV-1000, KV-3000, KV-5000 Ethernet Keyence X86 XScale
Koyo OPC30CE-KYS-O DL-05, DL-06, DL-230, DL-240, DL-250, DL-260, DL-330, DL-340, DL-430, DL-440, DL-450, DL-460 Serial Direct Net X86 XScale
Koyo OPC30CE-KYE-O DL-05, DL-06, DL-230, DL-240, DL-250, DL-260, DL-330, DL-340, DL-430, DL-440, DL-450, DL-460 Ethernet LG Fast Ethernet X86 XScale
LG OPC30CE-LGGMS-O GLOFA-GMR, GLOFA-GM1, GLOFA-GM2, GLOFA-GM3, GLOFA-GM4, GLOFA-GM6, GLOFA-GM7 Serial LG CNet Dedicated X86 XScale
LG OPC30CE-LGGME-O GLOFA-GMR, GLOFA-GM1, GLOFA-GM2, GLOFA-GM3, GLOFA-GM4, GLOFA-GM6 Ethernet LG Fast Ethernet X86 XScale
LG OPC30CE-LGMKS-O K200S, K300S, K1000S, XGB, XGK, XGT Series Serial LG CNet Dedicated X86 XScale
LG OPC30CE-LGMKE-O K200S, K300S, K1000S, XGB, XGK, XGT Series Ethernet LG Fast Ethernet X86 XScale
Mitsubishi OPC30CE-MTS-O FX Type: FX1N, FX1NC, FX2N, FX2NC, FX3UC Serial Melsec X86 XScale
Mitsubishi OPC30CE-MTS-O F2 Type: F2-20M, F2-40M, F2-60M Serial Melsec X86 XScale
Mitsubishi OPC30CE-MTS-O A Type: AOJ2, AOJ2H, A1N, A1S, A1SH, A1SJ, A2A, A2CCPUC24, A2N, A2SH, A2U, A2U-S1, A2US, A2US-S1, A2USH-S1, A3A, A3N, A3U, A4U Serial Melsec X86 XScale
Mitsubishi OPC30CE-MTS-O QnA Type: Q2A, Q2A-S1, Q2AS, Q2ASH, Q2AS-S1, Q3A, Q4A, Q4AR Serial Melsec X86 XScale
Mitsubishi OPC30CE-MTS-O Q Type: Q00CPU, Q00JCPU, Q01CPU, Q02CPU, Q02CPU-A, Q02HCPU, Q02HCPU-A, Q06HCPU, Q06HCPU-A, Q12HCPU, Q25HCPU Serial Melsec X86 XScale
Mitsubishi OPC30CE-MTS-O Q PLC CPU Port Type: Q00CPU, Q02CPU Serial Melsec X86 XScale
Mitsubishi OPC30CE-MTE-O FX Type: FX3UC Ethernet MelsecNet X86 XScale
Mitsubishi OPC30CE-MTE-O A Type: A2A, A2N, A2U-S1, A2US, A3A Ethernet MelsecNet X86 XScale
Mitsubishi OPC30CE-MTE-O QnA Type: Q2A, Q2A-S1, Q2AS, Q2ASH, Q2AS-S1, Q3A, Q4A, Q4AR Ethernet MelsecNet X86 XScale
Mitsubishi OPC30CE-MTE-O Q Type: Q00CPU, Q00JCPU, Q01CPU, Q02CPU, Q02HCPU, Q06HCPU, Q12HCPU, Q25HCPU Ethernet MelsecNet X86 XScale
Mitsubishi OPC30CE-MTE-O QnU Type: Q03UDECPU, Q04UDEHCPU, Q06UDEHCPU, Q13UDEHCPU, Q26UDEHCPU Ethernet MelsecNet X86 XScale
Modbus OPC30CE-MDS-O ASCII/RTU Serial Modbus X86 XScale
Modbus TCP OPC30CE-MDE-O Ethernet Ethernet Modbus TCP X86 XScale
Omron OPC30CE-OMS-O C200H, C200HE, C200HE-Z, C200HG, C200HG-Z, C200HS, C200HX, C200HX-Z, C500, C1000H, C2000H, CJ1G-H, CJ1H-H, CJ1M, CJ1G, CQM1H, CS1G, CS1H, CV500, CV1000, CV2000, CVM1, CVM1-V2, CP1-E, CP1-L, CP1-H Serial Hostlink X86 XScale
Omron OPC30CE-OME-O C200HE, C200HE-Z, C200HG, C200HG-Z, C200HX, C200HX-Z, CJ1G-H, CJ1H-H, CJ1M, CJ1G, CS1G, CS1H, CV500, CV1000, CV2000, CVM1, CVM1-V2, CP1-E, CP1-L, CP1-H Ethernet FinsUDP
FinsTCP/IP		 X86 XScale
Omron OPC30CE-OMFS-O C200H, C200HE, C200HE-Z, C200HG, C200HG-Z, C200HS, C200HX, C200HX-Z, C500, C1000H, C2000H, CJ1G-H, CJ1H-H, CJ1M, CJ1G, CQM1H, CS1G, CS1H, CV500, CV1000, CV2000, CVM1, CVM1-V2, CP1-E, CP1-L, CP1-H Serial Fins Serial X86 XScale
Panasonic OPC30CE-PSS-O FP all series Serial MEWTOCOL X86 XScale
PCM Inverter OPC30CE-PCM-O The driver support all PCM series Inverter. It needs to use with Modbus Card. Serial Modbus X86 XScale
Schneider OPC30CE-SNS-O FC30, FC34, FC400, FC440, FC600, FC640, FC660 Serial Uni-telway X86 XScale
Schneider OPC30CE-MDS-O Modicon 384, Modicon 484, Modicon 584, Modicon 884, Modicon 984, Micro 84, Modcell Serial Modbus X86 XScale
Schneider OPC30CE-MDE-O Modicon 384, Modicon 484, Modicon 584, Modicon 884, Modicon 984 Ethernet ModbusTCP X86 XScale
Schneider OPC30CE-MDS-O Square D Power Meter Serial Modbus X86 XScale
Schneider OPC30CE-MDS-O Sepam1000, Sepam2000 relay Serial Modbus X86 XScale
Siemens OPC30CE-SMM-O S7-200 Serial PPI X86 XScale
Siemens OPC30CE-SMM-O S7-200, S7-300, SIPLUS S7-300, S7-400, S7-400H/F/FH Serial MPI X86 XScale
Siemens OPC30CE-SME-O S7-200, S7-300, SIPLUS S7-300, S7-400, S7-400H/F/FH, S7-1200, S7-1500 Ethernet Siemens
Profinet		 X86 XScale
Toshiba OPC30CE-TSS-O EX series:EX100, EX250, EX500, EX2000
T series: T1/T1S, T2/T2E/T2N, T3/T3H/T3V, S2E/S2T
V series: Model 1000(L1), Model 2000(S2),
Model 3000(S3)		 Serial Toshiba ASCII Computer Link X86 XScale
Toshiba OPC30CE-TSE-O EX series:EX100, EX250, EX500
T series: T2N, T3H, S2T/S2E
V series: Model 1000(L1), Model 2000(S2), Model 3000(S3)		 Ethernet Toshiba ASCII Computer Link X86 XScale
Triconex OPC30CE-MDS-O Triconex Triplex PLC via Modbus Serial Modbus X86 XScale
TraceTel OPC30CE-MDS-O TraceTel Water Leakage Serial Modbus X86 XScale
Valmet Automation OPC30CE-MDS-O DAMATROL MC100, MC300, MC512H Serial Serial Modbus X86 XScale
VIGOR OPC30CE-VGS-O VB0, VB1, VB2, VH-10MR, VH-14MR, VH-20MR, VH-24MR, VH-28MR, VH-32MR, VH-40MR, VH-60MR, VH-20AR, M1-CPU1 Serial Computer
Link		 X86 XScale
Yaskawa OPC30CE-YSS-O Memocon U-84, Memocon U-84J, Memocon U-84S, Memocon GL40S, Memocon GL60S, Memocon GL60H, Memocon GL70H, Memocon GL120, Memocon GL130, Control Pack CP-9200SH, PROGIC-8 PRIGIC-8 Serial MEMOBUS X86 XScale
Yaskawa OPC30CE-YSE-O CP9200, CP9200H, CP9200SH Ethernet MEMOBUS X86 XScale
Yaskawa OPC30CE-YSS-O MP920, MP930, MP940, MP2200, MP2300S, MP2300, MP2310, MP2400 Serial MEMOBUS X86 XScale
Yaskawa OPC30CE-YSE-O MP920, MP930, MP940, MP2200, MP2300S, MP2300, MP2310, MP2400 Ethernet MEMOBUS X86 XScale
Yaskawa OPC30CE-YSI-O A1000, V1000, J1000, T1000 Serial MEMOBUS X86 XScale
Yokogawa OPC30CE-YKS-O FA-M3 series Serial AceFAM3 X86 XScale
Yokogawa OPC30CE-YKE-O FA-M3 series Ethernet AceFAM3 X86 XScale
Zworld OPC30CE-MDS-O Zworld MicroG Controller Serial Modbus X86 XScale
OPCTechs OPC30CE-Tool-NET OPC Tools For .NET X86 XScale
